node-moleculer-web
TypeScript icon, indicating that this package has built-in type declarations

1.1.7 • Public • Published

node-moleculer-web

Install

npm install node-moleculer-web --save

or

yarn add node-moleculer-web

or

npm i github:sanchezzzhak/node-moleculer-web#v1.1.4

Uses

1 Create controller in folder controllers/home.js

const {AbstractController} = require('node-moleculer-web');
class HomeController extends AbstractController {
  async index() {
    return `helo world`;
  }
}
module.exports = HomeController

2 Create service in folder services/app.service.js

const {UwsServer} = require('node-moleculer-web');
const {Service} = require('moleculer');

const HomeController = require('../controllers/home');

class AppService extends Service {
  constructor(broker) {
    super(broker);
    this.parseServiceSchema({
      name: 'app',
      settings: {
          // base port for server
          port: process.evn.SERVER_PORT ?? 3101,
            // on what ip to listen
          ip: process.evn.SERVER_IP ?? '127.0.0.1',
          // web-service registration type
            // node (ports will be assigned +1 from the current one)
            // auto (ports will be assigned +1 from the current one if the port is free)
          portSchema: process.evn.SERVER_SCHEMA ?? 'node',
            // if statics are not needed, just remove this parameter
          publicDir: __dirname + '/../public',
            // list of controllers
          controllers: {
             home: HomeController
          }
      },
      mixins: [
          UwsServer
      ],
      created: this.createService
    })
  }

  createService() {
    // register routing where home is the controller and index is the method
    this.createRoute('get / #c:home.index')
    this.bindRoutes();
  }
}
module.exports = AppService

Router path

  • <request type> / #c:<controller name>.<action>
  • <request type> / #s:<service name>.<action>
  • allowed request types:
  • any - HTTP ALL
  • connect - HTTP CONNECT
  • del - HTTP DELETE
  • get - HTTP GET
  • head - HTTP HEAD
  • options - HTTP OPTIONS
  • patch - HTTP PATCH
  • post - HTTP POST
  • put - HTTP PUT
  • trace - HTTP TRACE

Router Options

  • cache - second http cache
  • onBefore(route, req, res) - Function before call for controller or service
  • onAfter(route, req, res) - Function after call for controller or service

Example options for createRoute

this.createRoute('get / #c:home.index', {cache: 5});
this.bindRoutes();

Controller API

  • properties:
property description
requestData read request data
cookieData read/write cookie
requestData or cookieData (The property objects are available after executing the this.initRequest() method inside the controller method)
redirectType "header" | "meta" | "js" (default meta)
format default response content type default html
statusCode default response http code number 200
statusCodeText default response http code string 200 OK

Example Controllers

response json object

class Home extends AbstractController {
  async index() {
   return this.asJson({}, 200);
  }
}

response redirect to other url

class Home extends AbstractController {
  async index() {
    return this.redirect('https://youdomain.dev', 301);
  }
}

response ejs template

class Home extends AbstractController {
  async index() {
    return this.render({
      template, params, httpCode: 200, format: 'html'
    });
  }
}

response raw

class Home extends AbstractController {
  async index() {
    return this.renderRaw({view: 'string', httpCode: 200, format: 'html'});
  }
}

or

class Home extends AbstractController {
  async index() {
    return 'Hello World'
  }
}

Read or Write Cookie

class Home extends AbstractController {
  async index() {
    this.initRequest();
    // read
    const cookievalue= this.cookieData.get('my_cookievalue', 1*new Date);
    // write
    this.cookieData.set('my_cookievalue', cookievalue)

    return cookievalue;
  }
}

get request data

class Home extends AbstractController {
  async index() {
    this.initRequest();
    const headers = this.requestData.headers;
    const ip = this.requestData.ip;
    const query = this.requestData.query ?? {};
    const referer = this.requestData.referer;
    const currentUrl = this.requestData.url;
    const userAgent = this.requestData.userAgent;

    return this.asJson({headers, ip, query, referer, currentUrl, userAgent}, 200);
	}
}

call another microservice service in controller

class Home extends AbstractController {
  async index() {
   const data = await this.broker.call('service-name.action', {
      email: 'test'
   }) ?? {};

   return this.asJson(data, 200);
  }
}

read post body

class Home extends AbstractController {
  async index() {
    const body = await this.readBody();
     return this.asJson({body}, 200);
  }
}

NGINX config if request proxying is used for once instance

server {
  listen 80;
  listen 443 ssl;
  listen [::]:80;
  listen [::]:443;

  server_name domain.com;

  location / {
    proxy_http_version 1.1;
    proxy_set_header Host $http_host;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    proxy_set_header X-NginX-Proxy true;
    proxy_pass http://127.0.0.1:3001;
    proxy_redirect off;
  }
}

NGNIX config if clustering is used

Run locally

npx moleculer-runner -i 4 services

or

node node_modules/.bin/moleculer-runner -i 4 services

The config itself

upstream node_apps {
  server 127.0.0.1:3001;
  server 127.0.0.1:3002;
  server 127.0.0.1:3003;
  server 127.0.0.1:3004;
}

server {
  listen 80;
  listen 443 ssl;
  listen [::]:80;
  listen [::]:443;

  server_name domain.com;

  location / {
    proxy_http_version 1.1;
    proxy_set_header Host $http_host;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    proxy_set_header X-NginX-Proxy true;
    proxy_pass http://node_apps;
    proxy_redirect off;
  }
}

cluster config moleculer.config.js

module.exports = {
  nodeID: 'DEMO',
  transporter: "TCP",
  registry: {
    // type of call strategy for microservices
    strategy: "RoundRobin",
    // If set to true, then each webserver will use only its own micro-services
    preferLocal: false,
  },
  logger: console
};
