Graph Image

graph-image

Advanced Lazy-Loading and Compression with Svelte/SvelteKit and Hygraph

npm version downloads release status stars demo status npm bundle size npm bundle size

DemoObie Munoz

  • Automatically resize images according to your design specifications
  • Dynamically serve .webp format where supported, ensuring modern compression techniques are utilized for faster load times
  • Generate device-specific variants to ensure optimal download size
  • Prioritize initial page speed and conserve bandwidth
  • Employ the 'blur-in' technique or a solid background for seamless image loading experiences
  • Prevent page layout jumps with consistent image positioning

Special thanks to the creators and contributors of @graphcms/react-image for the work in React this project was based on.

Quickstart

Here's an example using a static asset object.

<script>
    import { GraphImage } from "graph-image";

    const asset = {
        handle: "uQrLj1QRWKJnlQv1sEmC",
        width: 800,
        height: 800
    }
</script>

<GraphImage image={asset} maxWidth={800} />
<GraphImage
	title="Example 2"
	alt="Example 2"
	image={{ handle: asset.handle, width: 1920, height: 1080 }}
	withWebp
	maxWidth={500}
	style={{
		width: '500px',
		margin: '32px 16px'
	}}
/>

Props

Name Type Description
image object An object of shape { handle, width, height }. Handle is an identifier required to display the image and both width and height are required to display a correct placeholder and aspect ratio for the image. You can get all 3 by just putting all 3 in your image-getting query.
maxWidth number Maximum width you'd like your image to take up. (ex. If your image container is resizing dynamically up to a width of 1200, put it as a maxWidth)
fadeIn bool Do you want your image to fade in on load? Defaults to true
fit "clip"|"crop"|"scale"|"max"|"center-contain" (Experimental) When resizing the image, how would you like it to fit the new dimensions? Defaults to crop. You can read more about resizing here. "center-contain" is experimental and will use 'clip' for the purposes for resizing.
withWebp bool If webp is supported by the browser, the images will be served with .webp extension. (Recommended)
title string Passed to the img element
alt string Passed to the img element
style object Spread into the default styles in the wrapper div
position string Defaults to relative. Pass in absolute to make the component absolute positioned
blurryPlaceholder bool Would you like to display a blurry placeholder for your loading image? Defaults to true.
backgroundColor string|bool Set a colored background placeholder. If true, uses "lightgray" for the color. You can also pass in any valid color string.
baseURI string Set the base src from where the images are requested. Base URI Defaults to https://media.graphassets.com
quality number Set the image quality value between 1 & 100
sharpen number Set the image sharpen value between 0 and 20
rotate number Set the image rotation between 0 & 360 degrees
watermark object An object of shape { handle, size, position }. Handle is an identifier required to display the image. size is an optional number. position is required and can either be a string HorizontalPosition or a tuple of shape [VerticalPosition, HorizontalPosition] where VerticalPosition can be 'top' | 'middle' | 'bottom' and HorizontalPosition can be 'left' | 'center' | 'right
load "lazy"|"eager" To prioritize loading speed, set load to eager. This will place preload tags in the <head> and will remove transition effects. Defaults to lazy.

Source and Image

You can also show the Source and Image components to show different images at different breakpoints.

<script>
	import { Image, Source } from 'graph-image';
</script>

<picture>
	<source
		handle="uQrLj1QRWKJnlQv1sEmC"
		alt="Mobile Image"
		width="{768}"
		height="{800}"
		media="(max-width: 600px)"
	/>
	<image handle="uQrLj1QRWKJnlQv1sEmC" alt="Desktop Image" width="{1920}" height="{1800}" />
</picture>

Preloading Source and Image

You can also Preload Source and Image components please note that because responsive preload has no notion of "order" or "first match", the media queries will need to be translated

<script>
	import { Image, Source } from 'graph-image';
</script>

<picture>
	<source
		handle="sdgegrrnlQvsd23vcl"
		alt="Mobile Image"
		width="{400}"
		height="{400}"
		media="(max-width: 400px)"
		preloadMedia="(max-width: 400px)"
	/>
	<source
		handle="adWEFKJnlQvsda1s12e"
		alt="MD Image"
		width="{768}"
		height="{800}"
		media="(max-width: 800px)"
		preloadMedia="(min-width: 400.1px and (max-width: 800px)"
	/>
	<image
		handle="uQrLj1QRWKJnlQv1sEmC"
		alt="Desktop Image"
		width="{1920}"
		height="{1800}"
		loading="eager"
		media="(min-width: 800.1px)"
	/>
</picture>
