gridjs-spreadsheet

A smart and simple to use WYSIWYG Excel-like JavaScript Canvas based Spreadsheet library allows you to view and edit spreadsheet file with ease and quick

Document

It allows you to view and edit spreadsheet documents with ease.

this is developed based on https://github.com/myliang/x-spreadsheet

Quick online demo: https://products.aspose.app/cells/editor

CDN

<head>
<!-- other dependency start -->
<link rel="stylesheet" href="https://unpkg.com/bootstrap@5.2.3/dist/css/bootstrap.min.css">
<link rel="stylesheet" href="https://unpkg.com/jquery-ui@1.13.2/dist/themes/ui-lightness/jquery-ui.min.css">
<script src="https://unpkg.com/jquery@3.6.0/dist/jquery.min.js"></script>
<script src="https://unpkg.com/jquery-ui@1.13.2/dist/jquery-ui.min.js"></script>
<script src="https://unpkg.com/jszip@3.10.1/dist/jszip.min.js"></script>
<!-- other dependency end -->
<link rel="stylesheet" href="https://unpkg.com/gridjs-spreadsheet@24.1.0/xspreadsheet.css">
<script src="https://unpkg.com/gridjs-spreadsheet@24.1.0/xspreadsheet.js"></script>

<script>
     const option = {
                updateMode: 'server',
                updateUrl: '/GridJs2/UpdateCell',
                showToolbar: true,
                //mode: 'edit' or 'read'
                mode: 'read',
                //support multiple language ,the locale is:en, cn, es, pt, de, ru, nl, ar, fr,id,it,ja, ko,th,tr,vi,cht
                local: 'en',
            };
    const sheetstr="[{\"name\":\"Sheet1\",\"sheetid\":\"s0\",\"showGrid\":true,\"sprotected\":false,\"canselectlocked\":true,\"displayRight2Left\":false,\"canselectunlocked\":true,\"styles\":[{\"textwrap\":true,\"color\":\"#000000\",\"valign\":\"middle\",\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"italic\":false}},{\"textwrap\":false,\"color\":\"#000000\",\"valign\":\"middle\",\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"italic\":false}}],\"cols\":{\"0\":{\"width\":72},\"1\":{\"width\":72},\"2\":{\"width\":532},\"3\":{\"width\":72},\"4\":{\"width\":72},\"5\":{\"width\":72},\"6\":{\"width\":72},\"7\":{\"width\":72},\"8\":{\"width\":72},\"9\":{\"width\":72},\"10\":{\"width\":72},\"11\":{\"width\":72},\"12\":{\"width\":72},\"13\":{\"width\":72},\"14\":{\"width\":72},\"15\":{\"width\":72},\"len\":16},\"rows\":{\"3\":{\"height\":122,\"cells\":{\"2\":{\"text\":\"FFF呜呜呜\\n呜我 我我我我\\nnice wwwwww\\nexample work 测的的的的的的的到\\n到手            一级 一季报 击败发发发发发发发发发发发\",\"style\":0,\"rtxt\":[{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#000000\",\"italic\":false},\"txt\":\"F\"},{\"font\":{\"name\":\"arial\",\"size\":18,\"bold\":false,\"color\":\"#953735\",\"italic\":false},\"txt\":\"FF呜\"},{\"font\":{\"name\":\"arial\",\"size\":18,\"bold\":false,\"color\":\"#953735\",\"underline\":\"single\",\"italic\":false},\"txt\":\"呜\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#000000\",\"underline\":\"single\",\"italic\":false},\"txt\":\"呜\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#000000\",\"italic\":false},\"txt\":\"\\n呜\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#0070C0\",\"italic\":false},\"txt\":\"我 我我\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#000000\",\"italic\":false},\"txt\":\"我我\\nni\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":true,\"color\":\"#C00000\",\"italic\":true},\"txt\":\"ce wwwwww\\nexample\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#000000\",\"italic\":false},\"txt\":\" work \"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#C0504D\",\"italic\":false},\"txt\":\"测的的的\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#C0504D\",\"underline\":\"double\",\"italic\":false},\"txt\":\"的的\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#000000\",\"underline\":\"double\",\"italic\":false},\"txt\":\"的\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#000000\",\"italic\":false},\"txt\":\"的到\\n到手            \"},{\"font\":{\"name\":\"arial\",\"size\":18,\"bold\":false,\"color\":\"#000000\",\"italic\":false},\"txt\":\"一级 一季\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#000000\",\"italic\":false},\"txt\":\"报 击败发\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#9BBB59\",\"italic\":false},\"txt\":\"发发发发发发\"},{\"font\":{\"name\":\"arial\",\"size\":11,\"bold\":false,\"color\":\"#000000\",\"italic\":false},\"txt\":\"发发发发\"}],\"html\":\"<Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #000000;\\\">F</Font><Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 18pt;COLOR: #953735;\\\">FF呜</Font><Font Style=\\\"TEXT-DECORATION: underline;FONT-FAMILY: arial;FONT-SIZE: 18pt;COLOR: #953735;\\\">呜</Font><Font Style=\\\"TEXT-DECORATION: underline;FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #000000;\\\">呜</Font><Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #000000;\\\"><Br>呜</Font><Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #0070c0;\\\">我 我我</Font><Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #000000;\\\">我我<Br>ni</Font><Font Style=\\\"FONT-WEIGHT: bold;FONT-STYLE: italic;FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #c00000;\\\">ce wwwwww<Br>example</Font><Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #000000;\\\">&nbsp;work </Font><Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #c0504d;\\\">测的的的</Font><Font Style=\\\"TEXT-DECORATION: underline;FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #c0504d;\\\">的的</Font><Font Style=\\\"TEXT-DECORATION: underline;FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #000000;\\\">的</Font><Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #000000;\\\">的到<Br>到手            </Font><Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 18pt;COLOR: #000000;\\\">一级 一季</Font><Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #000000;\\\">报 击败发</Font><Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #9bbb59;\\\">发发发发发发</Font><Font Style=\\\"FONT-FAMILY: arial;FONT-SIZE: 11pt;COLOR: #000000;\\\">发发发发</Font>\"},\"4\":{\"text\":\"\",\"style\":1}}},\"len\":13,\"height\":19}},{\"name\":\"Sheet2\",\"sheetid\":\"s1\",\"showGrid\":true,\"sprotected\":false,\"canselectlocked\":true,\"displayRight2Left\":false,\"canselectunlocked\":true,\"cols\":{\"0\":{\"width\":72},\"1\":{\"width\":72},\"2\":{\"width\":72},\"3\":{\"width\":72},\"4\":{\"width\":72},\"5\":{\"width\":72},\"6\":{\"width\":72},\"7\":{\"width\":72},\"8\":{\"width\":72},\"9\":{\"width\":72},\"10\":{\"width\":72},\"11\":{\"width\":72},\"12\":{\"width\":72},\"13\":{\"width\":72},\"14\":{\"width\":72},\"15\":{\"width\":72},\"len\":16},\"rows\":{\"12\":{\"height\":19,\"cells\":{\"15\":{\"text\":\"\"}}},\"len\":13,\"height\":19}},{\"name\":\"Sheet3\",\"sheetid\":\"s2\",\"showGrid\":true,\"sprotected\":false,\"canselectlocked\":true,\"displayRight2Left\":false,\"canselectunlocked\":true,\"cols\":{\"0\":{\"width\":72},\"1\":{\"width\":72},\"2\":{\"width\":72},\"3\":{\"width\":72},\"4\":{\"width\":72},\"5\":{\"width\":72},\"6\":{\"width\":72},\"7\":{\"width\":72},\"8\":{\"width\":72},\"9\":{\"width\":72},\"10\":{\"width\":72},\"11\":{\"width\":72},\"12\":{\"width\":72},\"13\":{\"width\":72},\"14\":{\"width\":72},\"15\":{\"width\":72},\"len\":16},\"rows\":{\"12\":{\"height\":19,\"cells\":{\"15\":{\"text\":\"\"}}},\"len\":13,\"height\":19}}]";
    xs = x_spreadsheet('#gridjs-demo', option).loadData(JSON.parse(sheetstr)).change((cdata) => {
                console.log(cdata);
                console.log(xs.validate());
            }
</script>
</head>
   <body>
     <div id="gridjs-demo"></div>
   </body>

NPM

npm install gridjs-spreadsheet
<div id="gridjs-demo"></div>
//includ all the dependencies
//Including jszip
import JSZip from 'jszip';
window.JSZip = JSZip;
//Including jQuery
import $ from 'jquery';
window.$ = $;
//Including gridjs-spreadsheet
import 'gridjs-spreadsheet/xspreadsheet.css';
import Spreadsheet from "gridjs-spreadsheet";

// If you need to override the default options, you can set the override
// const options = {};
// new Spreadsheet('#gridjs-demo', options);
const s = new Spreadsheet("#gridjs-demo")
  .loadData({}) // load data
  .change(data => {
    // save data to db
  });



simple usage


// If you need to override the default options, you can set the override
 const option = {
                updateMode: 'server',
                updateUrl: '/GridJs2/UpdateCell',
                showToolbar: true,
                //mode: 'edit' or 'read'
                mode: 'read',
                //support multiple language ,the locale is:en, cn, es, pt, de, ru, nl, ar, fr,id,it,ja, ko,th,tr,vi,cht
                local: 'en',
            };

 xs = x_spreadsheet('#gridjs-demo', option).loadData(sheets).change((cdata) => {
                console.log(cdata);

            }


// default options
{
  mode: 'edit', // edit | read
  showToolbar: true,
  showGrid: true,
  showContextmenu: true,
  view: {
    height: () => document.documentElement.clientHeight,
    width: () => document.documentElement.clientWidth,
  },
  row: {
    len: 100,
    height: 25,
  },
  col: {
    len: 26,
    width: 100,
    indexWidth: 60,
    minWidth: 60,
  },
  style: {
    bgcolor: '#ffffff',
    align: 'left',
    valign: 'middle',
    textwrap: false,
    strike: false,
    underline: false,
    color: '#0a0a0a',
    font: {
      name: 'Helvetica',
      size: 10,
      bold: false,
      italic: false,
    },
  },
}

Bind events

//single selection
xs.on('cell-selected', (cell, ri, ci) => {});
//range selection
xs.on('cells-selected', (cell, { sri, sci, eri, eci }) => {});
//shape/image selection
xs.on('object-selected', (obj) => {  console.log('obj id:', obj.id, ', type: ', obj.type); })
// edited on cell
xs.on('cell-edited', (text, ri, ci) => {});

update cell-text


// cellText(ri, ci, text, sheetIndex = 0)
xs.cellText(5, 5, 'xxxx',0).cellText(6, 5, 'yyy',0).reRender();

get cell and cell-style


// cell(ri, ci, sheetIndex = 0)
xs.cell(ri, ci);
// cellStyle(ri, ci, sheetIndex = 0)
xs.cellStyle(ri, ci);

Features

  • Localization/Multiple language UI
  • Paint format
  • Clear format
  • Format
  • Font/Font size/ bold/italic/Underline/Strike
  • Highlight
  • Shape/Image resize/rotate/position ajustment
  • Text color/Align/wrapping
  • Fill color
  • RichText
  • Borders
  • Merge cells
  • Freeze cell
  • Copy, Cut, Paste
  • Autofill
  • Insert/Delete row, column
  • Filter row, column
  • Zoom in/out
  • Sort
  • Search
  • Formula
  • Resize row-height, col-width
  • Switch/add/delete sheets
  • Condition Format
  • Comment
  • Add/delete Links
  • Print
  • Data validations
  • Insert picture from web page
  • Display chart/shapes
  • Display form controls /activeX controls
  • Insert/Delete form controls
  • Insert/Delete common shapes for autoshape
  • Support display two colors gradient in fill effects

Demo

Visit the GridJs demo to find more detail info https://github.com/aspose-cells/Aspose.Cells-for-.NET/tree/master/Examples_GridJs You can ask any question using the Forum.

Documentation

Online documentation is available here:

Browser Support

Modern browsers(chrome, firefox, Safari).

LICENSE

MIT
