onfido-sdk-ui

JavaScript SDK view layer for Onfido identity verification

Onfido SDK UI Layer

bitHound Overall Score bitHound Dependencies Build Status

Overview

This is a plug-and-play SDK that leverages the Onfido SDK core, helping users take document and face captures that can then be sent to our backend APIs.

The SDK uses WebSockets and the getUserMedia API (where supported) to capture via a user’s webcam, falling back to a file upload for unsupported browsers. The accept="image/*" attribute is used to give the option to take a photo using the native capture methods on handheld devices.

All document captures are sent over WebSockets to our image evaluation API, to ensure your users are submitting a document image of adequate quality.

To initialise the SDK, a connection to our WebSocket endpoint is required. Connections are authorized using JWTs, which can be generated on your server, or fetched from our JWT endpoint. Read about how to do this in the authentication section below.

Screenshots

Various views from the SDK

Example

To get up and running with the library, there are three things you need to include.

1. Include/Import the library

1.1 HTML Script Tag Include

Include it as a regular script tag on your page:

<script src='dist/onfido.min.js'></script>

And the CSS styles:

<link rel='stylesheet' href='dist/styles.css'>

Example app

JsFiddle example here. Simple example using script tags.

1.2 NPM style import

You can also import it as a module into your own JS build system (tested with Webpack).

$ npm install --save onfido-sdk-ui
// ES6 module import
import Onfido from 'onfido-sdk-ui'

// commonjs style require
var Onfido = require('onfido-sdk-ui')

The CSS style will be included inline with the JS code when the library is imported.

Notice

The library is Browser only, it does not support the Node Context.

Example App

Webpack Sample App repository here. Example app which uses the npm style of import.

2. Some markup

There are just two things required in your HTML:

  1. A button that triggers the modal to open
  2. An empty element for the modal interface to mount itself on
<!-- Somewhere on your page you need a button or link that triggers
the verification modal to open -->
<button id='onfido-button' disabled>Verify identity</button>

<!-- At the bottom of your page, you need an empty element where the
verification component will be mounted. It’s very important that you
set a style of `display: none` on this too, otherwise it will display
on your page -->
<div id='onfido-mount' style='display: none'></div>

3. SDK init code

An example of how the SDK is initialised with all the available options used. These are broken down into more detail below.

Onfido.init({
  // the token that you generate on your server
  token: 'your-jwt-token',
  // id of the element you want to mount the component on
  containerId: 'onfido-mount',
  // here are various callbacks that fire during the capture process
  onReady: function() {
    // callback that fires when successfully authorised
  },
  onDocumentCapture: function(capture) {
    // callback for when the document has captured successfully
  },
  onFaceCapture: function(capture) {
    // callback for when the face capture was successful
  },
  onComplete: function(capturesHash) {
    // callback for when everything is complete
  },
  steps: [
    //you can customize the flow of different steps of the SDK flow
    //you can change the order or remove steps
    'welcome','document','face','complete'
  ]
})

4. Change options in runtime

It's possible to change the options initialised at runtime. Example below.

onfidoOut = Onfido.init({...})
...
//Change the title of the welcome screen
onfidoOut.setOptions({
  steps: [
    {
      type:'welcome',
      options:{title:"New title!"}
    },
    'document',
    'face',
    'complete'
  ]
});
...
//replace the jwt token
onfidoOut.setOptions({ token:"new token" });
...
//Open the modal
onfidoOut.setOptions({ isModalOpen:true });

The new options will be shallowly merged with the previous one. So one can pass only the differences to a get a new flow.

Public options and methods

A breakdown of the options and methods available to the SDK.

  • token {String} required

    A JWT is required in order to authorise with our WebSocket endpoint. If one isn’t present, an exception will be thrown.

  • useModal {Boolean} optional

    Turns the SDK into a modal, which fades the background and puts the SDK into a contained box.

  • isModalOpen {Boolean} optional

    In case useModal is set to true, this defines whether the modal is open or closed. To change the state of the modal after calling init() you need to later use setOptions() to modify it. The default value is false.

  • buttonId {String} optional

    In case useModal is set to true, the button with this ID, when clicked, will open the verification modal. This defaults to onfido-button, although is not necessary to have a button at all.

  • containerId {String} optional

    A string of the ID of the container element that the UI will mount to. This needs to be an empty element, and should be set to display: none. This defaults to onfido-mount.

  • onReady {Function} optional

    Callback function that fires once the library has successfully authenticated using the JWT. In this function we recommend removing the disabled attribute on the modal trigger button.

  • onDocumentCapture {Function} optional

    Callback that fires when the document has been successfully captured and confirmed by the user. It returns an object that contains the document capture.

  • onFaceCapture {Function} optional

    Callback that fires when the face has been successfully captured and confirmed by the user. It returns an object that contains the face capture.

  • onComplete {Function} optional

    Callback that fires when both the document and face have successfully been captured. It returns an object that contains both captures. This event data should sent to your backend where the full API requests will be made.

  • steps {List} optional

    List of the different steps in the flow. Each step is defined by a named string. The available steps can found at StepComponentMap.js

    It's also possible to pass parameters to each step. Eg:

    steps: [
      {
        type:'welcome',
        options:{
          title:'Open your new bank account'
        }
      },
      'document'
    ]

    In the example above the step 'welcome' will also pass the values inside of options to the properties (props) of the React components that make up the step. In order to know which props exist for each step, please read the source code for each component. The mapping between steps to components can be found at StepComponentMap.js

Completing the check

This SDK’s aim is to help with the document capture process. It does not actually perform the full document checks against our API.

In order to perform a full document check, you need to send the captures to your own server, and then make the call to our API with the captures included.

Built into the core is a getCaptures convenience method that returns back an object containing your captures.

// assigning the captures to a variable
var captures = Onfido.getCaptures()

You should get something returned back that looks like this:

{
  documentCapture: {
    //local id of the capture
    //useful only if you want to track and reference captures which have been taken
    id: "mwxm5loxdu63zlkawcdi",
    //base 64 encoded png image
    //the result of the document selection step
    documentType: "passport"
  },
  faceCapture: {
    id: "yy5j8hxlxukufjbrzfr",
  }
}

With this data, you will want to send it over to your backend, either by attaching it to a form, and submitting it inline, or asynchronously. If going for the latter, the onComplete callback is the best to use.

Here is a more complete example:

Onfido.init({
  token: 'your-jwt-token',
  buttonId: 'onfido-button',
  containerId: 'onfido-mount',
  // here we send the data in the complete callback
  onComplete: function() {
    var data = Onfido.getCaptures()
    sendToServer(data)
  }
})

function sendToServer(data) {
  var request = new XMLHttpRequest()
  request.open('POST', '/your/server/endpoint', true)
  request.setRequestHeader('Content-Type', 'application/json')
  var dataString = JSON.stringify(data)
  request.send(dataString)
}

Authentication

Clients are authenticated using JSON Web Tokens (JWTs). The tokens are one use only and expire after 30 minutes. See here for details on how JWTs work.

You need a new JWT each time you initialise the SDK. You can obtain a JWT in two ways:

1. Through Onfido's API

The Onfido API exposes a JWT endpoint. See the API documentation for details.

2. Generate your own

You can generate your own JWTs.

  • Algorithm: HS256.
  • Secret: Your Onfido API key.

Payload

The payload is not encrypted. Do not put your API key in the payload.

The payload keys are case sensitive and should all be lowercase.

  • exp {Integer} required

    The expiry time - UNIX time as an integer. This must be less than 30 minutes in the future.

  • jti {String} required

    The one-time use unique identifier string. Use a 64 bit random string to avoid collisions. E.g. "JTiYyyRk3w8"

  • uuid {String} required

    A unique ID that identifies your API token in our database. This can be shared publicly and is not the same as your API Token. We will provide you with your uuid on request.

  • ref {String} required

    The HTTP referrer of the page where the SDK is initialised. See the API documentation for allowed formats.

How is the Onfido SDK licensed?

The Onfido SDK core and Onfido SDK UI layer are available under the MIT license.
